SUN-15/20/25K-SG02HP3-EU-DM3

Three Phase Hybrid Inverter | 15-25kW | 3 MPPT | HV Battery Supported

SUN-15/20/25K-SG02HP3-EU-DM3
  • SUN-15/20/25K-SG02HP3-EU-DM3
  • SUN-15/20/25K-SG02HP3-EU-DM3
  • SUN-15/20/25K-SG02HP3-EU-DM3
  • SUN-15/20/25K-SG02HP3-EU-DM3
  • SUN-15/20/25K-SG02HP3-EU-DM3
  • SUN-15/20/25K-SG02HP3-EU-DM3
  • SUN-15/20/25K-SG02HP3-EU-DM3
  • SUN-15/20/25K-SG02HP3-EU-DM3
  • 100% unbalanced output
  • AC couple to retrofifit existing solar system
  • Max. 10 pcs parallel for on-grid and off-grid
    operation; Support multiple batteries parallel
  • Max. charging/discharging current of 55A
  • High voltage battery, higher efficiency
  • 6 time periods for battery charging/discharging
  • Support storing energy from diesel generator
DOWNLOAD AREA
>> Download Datasheet <<

Technical Specifications

  • SUN-15/20/25K -SG02HP3-EU-DM3

  • Feedback
Model SUN-15K-SG02HP3-EU-DM3 SUN-20K-SG02HP3-EU-DM3 SUN-25K-SG02HP3-EU-DM3
Battery Input Data
Battery Type Lithium-ion
Battery Voltage Range(V) 160-700
Max.Charging/Discharging Current(A) 55
Charging Strategy for Li-ion Battery Self-adaption to BMS
Number of Battery input 1
PV String Input Data
Max. PV Access Power (W)
 30000 40000 50000
Max. PV Input Power（W） 24000 32000 40000
Max. PV Input Voltage（V） 1000
Start-up Voltage（V） 180
MPPT Voltage Range（V） 150-850
Rated PV Input Voltage(V) 600
Max Input Short-Circuit Current（A） 36+20+20
Max Operating PV Input Current（A） 54+30+30
No.of MPP Trackers/No.of Strings MPP Tracker 3/2+1+1
AC Input/Output Data
Rated AC Input/Output Active Power（W） 15000 20000 25000
Max. AC Input/Output Apparent Power （VA） 16500 22000 27500
Rated AC Input/Output Current（A） 22.8/21.8 30.4/29.0 37.9/36.3
Max. AC Input/Output Current（A） 25/24 33.4/31.9 41.7/39.9
Max. Continuous AC Passthrough (grid to load)（A） 60
Peak Power (off-grid)（W） 1.5 times of rated power,10s
Power Factor Adjustment Range 0.8 leading to 0.8 lagging
Rated input/output voltage 220/380V,230/400V 0.85Un-1.1Un 3L+N+PE
Rated Input/Output Grid Frequency/Range(Hz) 50/45-55, 60/55-65
Total Current Harmonic Distortion THDi <3% (of nominal power)
DC Injection Current <0.5%ln
Efficiency
Max. Efficiency 97.6%
Euro Efficiency 97.0%
MPPT Efficiency ＞99%
Equipment Protection
Integrated
DC Reverse Polarity Protection, AC Output Overcurrent Protection, Thermal Protection, AC Output Overvoltage
Protection, AC Output Short Circuit Protection, DC Component Monitoring, Arc Fault Circuit
Interrupter (optional), Anti-islanding Protection, DC Switch, Insulation Impedance Detection,
Residual Current Detection
Surge Protection Level TYPE II(DC), TYPE II(AC)
Interface
LCD/LED Display LCD+LED
Communication Interface WIFI, RS485, CAN
Monitor Mode
GPRS/WIFI/Bluetooth/4G
General Data
Operating Temperature Range (℃) -40 to +60℃, >45℃ Derating
Permissible Ambient Humidity 0-100%
Permissible Altitude 3000m
Noise (dB) ≤45
Ingress Protection(IP) Rating IP 65
Inverter Topology Non-Isolated
Over Voltage Category OVC II(DC),OVC III(AC)
Type of Cooling Intelligent Air Cooling
Warranty 5 Years/10 Years
the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy
Grid Regulation IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002,
OVE-Richtlinie R25, G99, VDE-AR-N 4105
Safety EMC/Standard IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
