SUN-5/6/8/10/12K-SG05LP2-US-SM2/SM3

Split Phase Hybrid Inverter  | 5-12kW | 2/3 MPPT | LV Battery Supported

SUN-5/6/8/10/12K-SG05LP2-US-SM2/SM3
  • SUN-5/6/8/10/12K-SG05LP2-US-SM2/SM3
  • SUN-5/6/8/10/12K-SG05LP2-US-SM2/SM3
  • SUN-5/6/8/10/12K-SG05LP2-US-SM2/SM3
  • SUN-5/6/8/10/12K-SG05LP2-US-SM2/SM3
  • SUN-5/6/8/10/12K-SG05LP2-US-SM2/SM3
  • SUN-5/6/8/10/12K-SG05LP2-US-SM2/SM3
  • Colorful touch LCD, IP65 protection degree
  • AC couple to retrofifit existing solar system
  • Max. 16 pcs parallel for on-grid and off-grid
    operation; Support multiple batteries parallel
  • Max. charging/discharging current of 220A
  • 4ms on/off-grid switching
  • Support storing energy from diesel generator
  • 6 time periods for battery charging/discharging

DOWNLOAD AREA
>> Download Datasheet <<

Technical Specifications

  • SUN-(5-12)K-SG05LP2-US-SM2/SM3
  • Feedback
Model SUN-5K-SG05LP2-US-SM2 SUN-6K-SG05LP2-US-SM2 SUN-8K-SG05LP2-US-SM2 SUN-10K-SG05LP2-US-SM3 SUN-12K-SG05LP2-US-SM3
Battery Input Data
Battery Type Lead-acid or Lithium-ion
Battery Voltage Range(V) 40-60
Max. Charging/Discharging Current (A) 120 135 190 220 220
Charging Strategy for Li-ion Battery Self-adaption to BMS
Number of battery input 2
PV String Input Data
Max DC Input Power（W） 8000 9600 12800 16000 19200
Max DC Input Voltage（V） 500
Start-up Voltage（V） 125
MPPT Voltage Range（V） 150-425
Rated DC Input Voltage(V) 370
Max. Operating PV Input Current (A) 18+18
 32+32 32+32+32
Max. Input Short-Circuit Current (A) 27+27
 60+60 60+60+60
No.of MPP Trackers/No.of String Per MPP Tracker

2/1+1

 2/2+2 3/2+2+2
AC Input/Output Data
Rated AC Input/Output Active Power（W） 5000 6000 8000 10000 12000
Max AC Input/Output Apparent Power （VA） 5000 6000 8000 10000 12000
Rated AC Input/Output Current（A） 20.9 25 33.4 41.7 50
Max AC Input/Output Current（A） 20.9 25 33.4 41.7 50
Max. Continuous AC Passthrough (grid to load) (A) 100
Peak Power (off-grid)（W） 2 times of rated power, 10s
Power Factor Adjustment Range 0.8 leading to 0.8lagging
Rated Input/Output Voltage/Range(V) 120/240, 120/208 0.88Un＜U＜1.1Un 2L+N+PE
Rated Input/Output Grid Frequency/Range 60/55-65
Total Current Harmonic Distortion THDi <3% (of nominal power)
DC Injection Current <0.5%ln
Efficiency
Max Efficiency 97.6%
Euro Efficiency 96.5%
MPPT Efficiency ＞99%
Equipment Protection
Integrated
DC Reverse Polarity Protection, AC Output Overcurrent Protection, Thermal Protection, AC Output Overvoltage
Protection, AC Output Short Circuit
Protection, DC Component Monitoring, Arc Fault Circuit Interrupter (optional), Anti-islanding Protection,
DC Switch, Insulation Impedance Detection,
Residual Current Detection
Surge Protection Level TYPE II(DC), TYPE II(AC)
Interface
LCD/LED Display LCD
Communication Interface WIFI, RS485, CAN
General Data
Operating Temperature Range -40 to +60℃, >45℃ Derating
Permissible Ambient Humidity 0-100%
Permissible Altitude 3000m
Noise ≤ 45
Ingress Protection(IP) Rating TYPE 3R
Inverter Topology Non-Isolated (solar), Isolated (battery
Over Voltage Category OVC II(DC),OVC IV(AC)
Cabinet size（W*H*D）[mm] 386×606.5×240（Excluding connectors and brackets）
Weight[kg] 29.2
Warranty 5 Years/10 Years
the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy
Type Of Cooling Intelligent air cooling
Grid Regulation IEEE 1547.1, SRD V2.0
Safety EMC/Standard FCC, UL 1741
